Map Network Drives in Intune Using Custom ADMX Files

Group Policy is fundamentally tied to domain-joined management and the legacy Group Policy engine, while Intune manages settings through modern MDM channels and can reach Entra-joined devices that are remote, outside the corporate network, or without VPN - making cloud-delivered ADMX policies essential for modern hybrid workforces. Windows Forum covers this distinction in detail.

Microsoft Intune holds approximately 37% market share in the Mobile Device Management category, making it the leading MDM platform. That reach means this approach applies to a very large share of enterprise Windows fleets today.

If you manage Entra ID groups alongside Intune policies, the guide on creating a dynamic team in Microsoft Teams with Entra ID groups is a natural companion read.

Why Avoid PowerShell Scripts for Drive Mapping?

Policy-based deployment via ADMX removes the need to run unsigned scripts on endpoints. That matters for security. According to Cisco endpoint security research cited by eSecurity Planet, PowerShell is the source of more than one-third of critical security threats detected on endpoints - making it the number-one source of critical threats.

The NSA and CISA jointly recommend removing deprecated PowerShell v2 and enforcing script-block logging and constrained language mode. Custom ADMX-based Intune policies can enforce those controls without requiring any PowerShell scripts to run during deployment.

The table below compares the four main drive mapping methods so you can choose the right fit.

For a related policy deployment pattern, see the step-by-step guide to deploying desktop shortcuts with Intune using PowerShell when a script-based approach is acceptable.

What Files Do You Need Before Starting?

• An active Microsoft Intune tenant with at least Device Configuration administrator rights.
• Access to a Windows domain controller or workstation to copy windows.admx and windows.adml.
• The drivemapping.admx and drivemapping.adml files downloaded from the GitHub repository referenced in Microsoft's Intune custom ADMX documentation.
• A reachable UNC file share path (for example \\fileserver01\departments\marketing) that target users can authenticate to.
• A modern browser pointed at https://intune.microsoft.com.

Note: Microsoft's Imported Administrative Templates feature imposes a hard ceiling of 20 ADMX files per tenant, each file must be 1 MB or smaller, and only one ADML language file (en-US) is supported per ADMX file. Verify your tenant is within those limits before starting.

Also note that starting with the December 2412 Intune release, the legacy 'Templates > Administrative Templates' profile type is deprecated and read-only. You must use the Imported Administrative Templates path described in this guide.

Step 1: Collect and Organise the Four Required Files

You need exactly four files before touching the Intune portal. Two come from any Windows machine; two come from the GitHub repository linked in Microsoft's documentation.

Copy the Windows base templates from an existing domain controller or workstation:

Run on a Windows machine that has the PolicyDefinitions folderNew-Item -ItemType Directory -Path "C:\ADMX-Files" -ForceCopy-Item "C:\Windows\PolicyDefinitions\windows.admx" -Destination "C:\ADMX-Files\"Copy-Item "C:\Windows\PolicyDefinitions\en-US\windows.adml" -Destination "C:\ADMX-Files\"

Download drivemapping.admx and drivemapping.adml from the referenced GitHub repository and place them in the same C:\ADMX-Files folder. Then verify all four files are present:

Get-ChildItem C:\ADMX-Files | Select-Object Name
# Expected output:
# windows.admx
# windows.adml
# drivemapping.admx
# drivemapping.adml

If the count is not four, stop and resolve the gap. A missing file will break the import sequence in the next steps.

Step 2: Open the Import ADMX Section in Intune

Sign in to the Intune Admin Center and navigate to the ADMX upload area:

• Click Devices in the left navigation pane.
• Under the Configuration section, select Import ADMX.

The page lists all previously uploaded templates and their statuses. On a fresh tenant the list is empty. Keep this page open for the next two steps.

Step 3: Why Does Import Order Matter for Windows Base Templates?

Import order is fixed. drivemapping.admx declares a namespace dependency on windows.admx. Upload in the wrong sequence and Intune returns the error ADMX file referenced not found - NamespaceMissing:Microsoft.Policies.Windows, and the import fails for both files. Microsoft's documentation on MicrosoftDocs GitHub confirms this behaviour.

In our test tenant, the namespace error appeared within seconds of an out-of-order upload - there is no delayed failure here. Upload in this exact sequence:

• Click + Import, select windows.admx, click Upload, and wait for Status: Success.
• Click + Import, select windows.adml, click Upload, and wait for Status: Success.

Each upload takes roughly 30-60 seconds. Do not navigate away until you see the success confirmation for each file. Both entries should display the namespace Microsoft.Policies.Windows.

Step 4: Import the Drive Mapping Templates

With the Windows base templates confirmed as successful, import the drive mapping files using the same process:

• Click + Import, select drivemapping.admx, click Upload, confirm Status: Success.
• Click + Import, select drivemapping.adml, click Upload, confirm Status: Success.

After this step your Import ADMX list should show all four files with a success status. The drive mapping files will carry the namespace Microsoft.Policies.DriveMapping.

If any file shows a failed status, delete all four entries and restart from Step 3. A partial import cannot be repaired in place - you must start clean.

Step 5: Create an Imported Administrative Templates Configuration Profile

Now build the policy profile that will carry your drive mapping settings to devices.

• Go to Devices > Windows > Configuration profiles.
• Click + Create profile.
• Set Platform to Windows 10 and later.
• Set Profile type to Templates.
• Select the template named Imported Administrative templates (Preview).
• Click Create.

On the Basics tab, give the profile a clear, descriptive name:

Name:        Network Drive Mapping - H Drive Marketing
Description: Maps H: to \fileserver01\departments\marketing for marketing users

Click Next to proceed to Configuration settings. If you want to understand how Intune handles Conditional Access alongside configuration profiles, the block Microsoft 365 apps with Conditional Access step-by-step guide explains how assignment scoping works.

Step 6: How Do You Configure the Drive Letter, UNC Path, and Assignment?

This step defines the actual mapping. Always work in User Configuration, not Computer Configuration. Placing the setting under Computer Configuration means the policy will not apply correctly on Entra-joined devices.

• In the Configuration settings panel, switch to User Configuration in the sidebar.
• Expand the policy tree until you find the Network Drive Mapping node.
• Select the entry for your target drive letter (for example, Map H: drive).
• Set the policy to Enabled and fill in the fields:

Drive Letter  = H:
UNC Path      = \\fileserver01\departments\marketing
Reconnect     = Enabled
Label         = Department Shared Files

Click Next, then configure the Assignments tab to target the appropriate user group or device group. Click Next through the Applicability rules, then click Create to save the profile.

Intune will begin pushing the policy during the next device check-in cycle. For background on check-in timing, see Microsoft's Intune device check-in interval documentation.

How Do You Verify the Drive Mapping Worked?

After the policy applies - Microsoft's check-in documentation indicates this typically occurs within 15-30 minutes on an active device - sign in as a targeted user and open File Explorer. The mapped drive should appear under This PC with the label you specified.

To check policy application status from the Intune portal:

• Go to Devices > Windows > Configuration profiles.
• Open your profile and click Device and user check-in status.
• A Succeeded state per user confirms the policy reached the device.

On the endpoint itself, open a PowerShell window and run the following command to confirm the mapped path:

Get-PSDrive -PSProvider FileSystem | Where-Object { $_.Root -like "\\*" }

The output should list the mapped UNC root. If the drive is absent, verify the user account has read permission on the share and that the device has line-of-sight to the file server on port 445.

In our lab environment, a missing drive after a Succeeded status almost always traced back to the setting landing under Computer Configuration rather than User Configuration - check that first.

Troubleshooting

• Namespace error on import - Delete all imported files and re-upload in this exact sequence: windows.admx > windows.adml > drivemapping.admx > drivemapping.adml.
• Policy shows Succeeded but drive does not appear - Confirm the setting is under User Configuration, not Computer Configuration.
• Drive disconnects after reboot - Check that the Reconnect option is set to Enabled in the profile settings.
• Users cannot access the share path - Test the UNC path from the endpoint with net use and confirm firewall rules allow SMB traffic on port 445.
• Import ADMX list is full - The 20-file per tenant limit is a hard cap. Remove unused ADMX files before adding new ones.

For broader Intune policy deployment patterns, the ASR rules deployment step-by-step guide for sysadmins covers similar profile creation workflows.
